Offering an expansive 1400 × 710 mm cutting bed backed by 60 metric tons of certified hydraulic shearing force, the VihoX-60CP stands as the largest manual four-column press in our auxiliary equipment portfolio. Powered by a heavy-duty 5.5 kW drive motor, this press accommodates oversized thermoformed packaging layouts, deep-draw medical packaging containers, and thick multilayer polymer sheets. Its massive 4.5-ton framework guarantees rock-solid platen parallelism and consistent cut depth across every corner of the table.
| Specification Parameter | Engineering Value (VihoX-60CP) | Production Advantage & Technical Impact |
|---|---|---|
| Peak Shearing Output | 60 T (Metric Tons) | Effortlessly cuts large-format dies, dense polymer sheets, thick plastic packaging, and industrial foam assemblies. |
| Expansive Bed Dimensions | 1400 × 710 mm | Spacious 1.4-meter cutting table accommodates wide thermoformed web layouts and multi-cavity gang dies. |
| Adjustable Ram Stroke | 50–240 mm | Flexible stroke length supports quick short-cycling on flat packaging or deep strokes for tall containers. |
| Platen Daylight Height | Approx. 50–200 mm | Generous opening height allows easy die installation and comfortable manual material positioning. |
| Electric Pump Rating | 5.5 kW | Heavy-duty motor provides rapid platen advance and powerful shearing pressure with low noise output. |
| Infeed Configuration | Manual Sheet Placement | Simple, dependable manual material handling layout ideal for medium-volume production runs. |
| Operator Protection | Dual Push-Button System | Requires concurrent two-hand input to initiate downward stroke, meeting strict CE safety standards. |
| Chassis Total Weight | Approx. 4000–4500 kg | Massive cast-iron construction damps hydraulic shock and preserves platen parallelism over years of use. |
| Exterior Measurements | Approx. 2200 × 1300 × 1500 mm | Sturdy industrial build provides maximum stability in high-volume packaging manufacturing bays. |
The structural frame of the VihoX-60CP is cast from high-density gray iron and stress-relieved to prevent warping under sustained 60-ton loads. Four ground and hard-chrome plated steel columns guide the moving platen, maintaining alignment within tight industrial tolerances. Precision mechanical balancing tie-bars synchronize both hydraulic cylinders, ensuring smooth, even descent even when cutting asymmetric dies.
The 5.5 kW hydraulic power unit incorporates high-flow directional valves and an adjustable pressure bypass circuit. Daylight opening reaches 200 mm, giving operators ample clearance to maneuver large dies and thick sheet materials. A precision micro-switch controls the bottom stroke limit, preventing excessive knife penetration into the cutting board.
Factory video illustrating the VihoX 60T four-column press slicing through thick thermoformed blister trays.
The VihoX-60CP performs heavy-duty secondary trimming downstream of large thermoforming machinery:
Its generous 1400×710 mm table and 60-ton hydraulic thrust easily accommodate large dies with extensive cutting knife perimeters.
Four ground guide pillars combined with heavy mechanical balancing link-bars force both cylinders to descend in complete synchronization.
Yes, the 60-ton capacity cuts heavy HDPE, ABS sheet, automotive carpet, sound insulation pads, and multi-layer packaging foams.
We recommend 25–30 mm thick high-density polypropylene (PP) or cast polyamide cutting pads for clean cutting and long tool life.
Depth is adjusted via an ergonomic micro-metric dial and limit switch mechanism, allowing precise bottom-stroke tuning in seconds.
The machine features standard two-hand interlocked start buttons, emergency stop palm buttons, and optional optical safety light curtains.
The hydraulic oil tank holds approximately 120 liters of ISO VG 46 anti-wear hydraulic oil, ensuring cool, stable operating temperatures.
Yes, our factory can extend pillar lengths to provide daylight openings up to 300 mm upon customer request.
