The VihoX-40CP introduces our high-precision four-column hydraulic press platform, engineered for packaging operations requiring strict platen parallelism across an expansive 1220 × 610 mm table area. Powered by dual synchronized hydraulic cylinders and a 3 kW drive motor, the 40CP delivers 40 metric tons of uniform clamping force. This setup eliminates platen tilting when cutting asymmetric blister tooling, ensuring that every cavity edge cuts clean without requiring manual paper shimming beneath the cutting pad.
| Specification Parameter | Engineering Value (VihoX-40CP) | Production Advantage & Technical Impact |
|---|---|---|
| Hydraulic Pressure Rating | 40 T (Metric Tons) | Delivers dependable cutting power for medium blister dies, automotive gaskets, sponge packaging, and leather goods. |
| Working Bed Dimensions | 1220 × 610 mm | Standard table format accommodates medium-format thermoformed sheet arrays and multi-cavity gang dies. |
| Platen Stroke Travel | 50–240 mm | Long stroke travel supports deep blister parts and multi-ply material stacks without requiring head shimming. |
| Daylight Platen Opening | Approx. 50–200 mm | Generous opening provides clear visibility and comfortable manual material infeed for operators. |
| Electric Pump Motor | 3 kW | Optimized motor size provides high hydraulic flow while maintaining modest factory energy bills. |
| Feed Kinematics | Manual Bed Infeed | Simple, reliable manual feed layout suited for packaging job shops and contract converters. |
| Operator Safeguards | Dual Interlocked Controls | Enforces two-hand button engagement during descent to guarantee operator hand safety. |
| Total Machine Mass | Approx. 2400 kg | Heavy welded steel chassis suppresses mechanical vibration, protecting tool edge sharpness over time. |
| Chassis Exterior Footprint | Approx. 1800 × 1100 × 1400 mm | Robust, self-contained rectangular build fits neatly into packaging plant finishing bays. |
Unlike cantilever clickers, the VihoX-40CP guides its upper pressing head along four precision-ground, hard-chromed pillar columns fitted with self-lubricating phosphor bronze sleeves. A mechanical balancing link bar connects the front and rear cylinder assemblies, mechanically forcing both ends of the platen to descend in lockstep even if cutting resistance is concentrated on one quadrant of the die.
The 50–240 mm stroke range accommodates diverse tool heights, while daylight clearance up to 200 mm allows easy handling of deep-draw blister shells. An electronic pressure switch senses hydraulic pressure buildup upon knife contact, triggering an immediate upward reversal to extend cutting pad longevity and minimize cycle time.
Factory operational run showing the VihoX four-column hydraulic cutting machine cleanly blanking thermoformed blister trays.
The VihoX-40CP is an essential secondary finishing unit downstream of primary forming machines:
The four-column structure provides superior platen parallelism over large table surfaces (1220×610 mm), preventing uneven cut depth on wide gang dies.
A precision balancing shaft ties the hydraulic rams together, ensuring both sides of the platen descend evenly regardless of die position.
Yes, stroke length can be set down to 50 mm via mechanical stop nuts and proximity sensors to speed up cycle rates on flat items.
It easily cuts single sheets up to 2.5 mm or multiple stacked plies of PET, PVC, PP, and PS, depending on total knife rule perimeter.
We recommend 68 liters of premium anti-wear hydraulic oil (ISO VG 46) for smooth valve response and pump protection.
While the 40CP is designed for manual feeding, our factory can configure semi-automatic pneumatic feed tables upon initial order.
Rotary handwheels and micro-metric adjustment dials on the side column allow precise setting of top dead center and bottom cutting depth.
We provide a 12-month comprehensive factory warranty on all structural frames, hydraulic cylinders, and electrical components.
